  • Specifications Table
    24V
    Passengers1
    Load Capacity300 lbs.
    Towing Capacity4,000 lbs.
    Speed5 mph
    Turning Radius53 "
    POWERTRAIN
    Motor6 hp shunt motor
    Drive AxleHelical gear differential
    TransmissionDirect drive
    ControllerSEPEX Electronic speed controller, Single right-hand side foot treadle for speed and brake control
    ENERGY
    Voltage24V
    BatteryFour 6V-220AH batteries
    ChargerHigh-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC
    CHASSIS
    Body14-G diamond-plate steel body, tubular frame
    SuspensionDual front wheels to ensure the stability
    BrakesSelf-adjusting H.D. drum brakes, regenerative braking
    Wheels4.8x8 LRB pneumatic tires
    SteeringAutomotive Steering Wheel
    SeatsPadded backrest
    EQUIPMENT
    LightsLED headlight
    IndicatorsBattery status indicator
    Accessories
    SafetyReverse alarm, Deadman foot switch, Horn
    VEHICLE
    Weight840 lbs.
    Height50"
    Length56"
    Width30"
    Wheel Base36"
    DECK
    Deck Height35"
    Deck Length13"
    Deck Width30"
    BATTERY
    Battery Weight
    Battery Height
    Battery Length
    Battery Width
  • FULL SPECIFICATIONS OF OUR 48V LITHIUM SOLUTION
    MT-160 / MT-180 6.2 Kwh (120 Ah) 1.2 Kwh 4h 120V or 240V 83.8 lbs
    9.3 Kwh (180 Ah) 4h 125.7 lbs
    2.4 Kwh 3h 240V
