  • SpecificationsTable
    36V36V HD36V SD
    Passengers111
    Load Capacity700 lbs.800 lbs.800 lbs.
    Towing Capacity6,000 lbs.10,000 lbs.16,000 lbs.
    Speed8 mph8 mph6 mph
    Turning Radius73 "72 "72 "
    POWERTRAIN
    Motor10 hp shunt motorBrushless AC motor, 7.5 HP Intermittent, 10 HP MaxBrushless AC motor, 7.5 HP Intermittent, 10 HP Max
    Drive AxleHelical gear differentialHelical gear differentialHelical gear differential
    TransmissionDirect driveDirect driveDirect drive
    ControllerSEPEX Electronic speed controllerAC Electronic speed controllerAC Electronic speed controller
    ENERGY
    Voltage36V36V36V
    BatteryNo battery includedNo battery includedNo battery included
    ChargerNo charger includedNo charger includedNo charger included
    CHASSIS
    Body14-G diamond-plate steel body, tubular frameAll-steel unibody constructionAll-steel unibody construction
    SuspensionCoil springs & shock absorbers (front and rear)Dual coil springs & shock absorbers front and Dual leaf springs on rearDual coil springs & shock absorbers front and Dual leaf springs on rear
    BrakesRear hydraulic drum brakes, hand lever parking brake, regenerative brakingRear hydraulic drum brakes, regenerative brakingRear hydraulic drum brakes, regenerative braking
    Wheels4.8x8 LRC pneumatic tires4.8x8 LRC pneumatic tires4.8x8 LRC pneumatic tires
    SteeringAutomotive steering wheelAutomotive steering wheelAutomotive steering wheel
    SeatsBucket seat on slide adjustersBucket seat on slide adjustersBucket seat on slide adjusters
    EQUIPMENT
    LightsLED headlight & tail/brake lightLED headlight & tail/brake lightLED headlight & tail/brake light
    IndicatorsBattery status indicatorMultifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability.Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability.
    Accessories36V/12V converter for 12-volt accessories, bolt-on bumpers and rear wheel guards36V/12V converter for 12-volt accessories, bolt-on front bumper36V/12V converter for 12-volt accessories, bolt-on front bumper
    SafetyReverse alarm, deadman seat switch, hornReverse alarm, deadman seat switch, hornReverse alarm, deadman seat switch, horn
    VEHICLE
    Weight1,000 lbs.1,000 lbs.1,200 lbs.
    Height41"41"41"
    Length81"79"79"
    Width39"38"38"
    Wheel Base52"52"52"
    DECK
    Deck Height26"25"25"
    Deck Length21"21"21"
    Deck Width39"38"38"
    BATTERY
    Battery Weight
    Battery Height17.50"17.50"17.50"
    Battery Length35.20"35.20"35.20"
    Battery Width16"16"16"
