  • SpecificationsTable
    36V48V48V HD
    Passengers111
    Load Capacity500 lbs.500 lbs.500 lbs.
    Towing Capacity16,000 lbs.16,000 lbs.20,000 lbs.
    Speed8 mph8 mph8 mph
    Turning Radius59 "59 "68 "
    POWERTRAIN
    Motor10 HP brushless AC motor15 HP brushless AC motor15 HP brushless AC motor
    Drive AxleHelical gear differentialHelical gear differentialHelical gear differential
    TransmissionDirect driveDirect driveDirect drive
    ControllerElectronic AC speed controllerElectronic AC speed controllerElectronic AC speed controller
    ENERGY
    Voltage36V48V48V
    BatteryNo battery includedNo battery includedNo battery included
    ChargerNo charger includedNo charger includedNo charger included
    CHASSIS
    BodyAll-steel unibody construction, 1" rear-end plate, powder coatingAll-steel unibody construction, 1" rear-end plate, powder coatingAll-steel unibody construction, 2" rear-end plate, powder coating
    SuspensionLeaf springs rear suspension systemLeaf springs rear suspension systemLeaf springs rear suspension system
    BrakesRear wheel hydraulic drum brakes, regenerative brakingRear wheel hydraulic drum brakes, regenerative brakingRear wheel hydraulic drum brakes, regenerative braking
    WheelsSolid tiresSolid tiresSolid tires
    SteeringAutomotive steering wheelAutomotive steering wheelAutomotive steering wheel
    SeatsSemi-suspension seat on slide adjustersSemi-suspension seat on slide adjustersSemi-suspension seat on slide adjusters
    EQUIPMENT
    LightsLED dual headlights & tail/brake lightsLED dual headlights & tail/brake lightsLED dual headlights & tail/brake lights
    IndicatorsMultifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capabilityMultifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capabilityMultifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability
    Accessories36V/12V converter for 12-volt accessories, backlit and sealed buttons48V/12V converter for 12-volt accessories, backlit and sealed buttons48V/12V converter for 12-volt accessories, backlit and sealed buttons
    SafetyReverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptapeReverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptapeReverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptape
    VEHICLE
    Weight1,600 lbs.1,600 lbs.2,000 lbs.
    Height58"58"58"
    Length62"62"72"
    Width38"38"38"
    Wheel Base40.75"40.75"49.5"
    DECK
    Deck Height26.5"26.5"26.5"
    Deck Length16.25"16.25"16.25"
    Deck Width37"37"37"
    BATTERY
    Battery Weight
    Battery Height24"24"24"
    Battery Length35.75"35.75"35.75"
    Battery Width16.75"16.75"26"
